| Cat. No | Temperature Range | Max Working Temp on the Thermostat | Max Working Temp on the Bulb | Dimension Off Copper Bulb (mm) | Dimension Off Stainless-Steel Bulb (mm) | Lunghezza Lenght | ||
|---|---|---|---|---|---|---|---|---|
| L | ⌀ | L | ⌀ | |||||
| TU-F,SPST 30-80 | 30°C-80°C | T100 | 120°C | 100MM | 6MM | 900MM | ||
| TU-V,SPDT 30-110 | 30°C-110°C | T100 | 121°C | 112MM | 5MM | 900MM | ||
| TU-V,SPD 4-40 | 4°C-40°C | T80 | 44°C | 180MM | 5MM | 900MM | ||
| TU-V,SPDT 50-220 | 5oC-220°C | T150 | 231°C | 121MM | 5MM | 900MM | ||
| TU-V,SPDT 50-300/900 | 50°C-300°C | T150 | 315°C | 175MM | 3MM | 900MM | ||
| TU-V,SPDT 50-300/1400 | 50°C-300°C | T150 | 315°C | 175MM | 3MM | 1400MM | ||
| TU-V,SPDT 50-300/1500 | 50°C-300°C | T150 | 315°C | 175MM | 3MM | 1500MM | ||
| TU-V,SPST 30-110 | 30°C-110°C | T100 | 121°C | 112MM | 5MM | 900MM | ||
| TU-V,SPST 50-300/900 | 50°C-300°C | T150 | 315°C | 175MM | 3MM | 900MM | ||
